DK-P450S Intelligent Selective Conformal Coating Machine
The DK-P450S is a high-performance intelligent selective conformal coating machine designed for precision PCB protection in industrial electronics manufacturing. Equipped with a 10L pressurized glue tank, automatic pressure regulation, and an integrated UV inspection system, it delivers consistent, defect-free coating results for batch and inline production environments.
Key Features
- Intelligent Selective Coating — Programmable spray patterns for precise PCB protection, reducing material waste by up to 30%
- 10L Pressurized Glue Tank — Automatic pressure regulation ensures consistent glue flow throughout production runs
- Integrated UV Inspection — Built-in UV light source enables real-time coating coverage verification
- Auto-Cleaning System — 3L cleaning solvent tank with programmable cleaning cycles prevents nozzle clogging
- Silent Extraction — Low-noise fume extraction system maintains clean air quality in the work environment
- Multi-Board Support — Programmable conveyor speed and spray width for PCBs up to 450×450 mm
Technical Specifications
| Model | DK-P450S |
| Max PCB Size | 450 × 450 mm |
| Coating Width | 2 – 20 mm (programmable) |
| Positioning Accuracy | ±0.1 mm |
| Conveyor Speed | 1 – 5 m/min |
| Glue Tank Capacity | 10 L (standard) + 3 L (cleaning) |
| Power Supply | AC 220V, 50/60 Hz |
| Air Supply | 0.5 – 0.7 MPa |
| Dimensions (L×W×H) | 1200 × 1100 × 1650 mm |
| Weight | ~350 kg |
