DK-JC450 UV Inspection Station
Key Features
- UV inspection for conformal coating quality verification
- High-intensity UV light for clear coating fluorescence
- Adjustable lighting intensity for different coating types
- Large viewing area for thorough inspection
- Ergonomic design reduces operator fatigue
- SMEMA compatible for inline integration
Technical Specifications
| Model | DK-JC450 |
| PCB Size (Max) | 450 x 450 mm |
| UV Light Source | High-power UV LED array |
| Wavelength | 365 nm |
| Magnification | 2x - 5x (optional) |
| Conveyor Height | 900 ± 20 mm |
| Power Supply | AC220V 50/60Hz |
| Dimensions | L800 x W900 x H1450 mm |
| Weight | ~120 kg |
×
